T6500W HIGH PRESSURE GAUGES
Description:
The Ashcroft® T6500W is a DIN 16001 ultra high pressure gauge with a solid front stainless steel case designed for high performance, increased safety and reliability. Features include 100mm and 160mm sizes and PLUS!™ performance.
Features:
- All-stainless steel movement
- Easily adjustable micrometer pointer
- Socket welded to case
- PLUS!™ Performance (optional)
Application:
- Chemical and Petrochemical
- Energy
- Food and Beverage
- Oil and Gas
- Machine Automation
- Hydrogen and Technical Gases
- Pharmaceuticals
- Pumps and Compressors
Reference:
8008S Pressure gauge
Description:
The Ashcroft® 8008S delivers the advanced features of a larger gauge in a small, economical package for applications requiring an all stainless steel instrument for harsh environments. Laser welded wetted 316L stainless steel components ensure system integrity for corrosive medias. A solid front case option is also available to enhance operator safety along with numerous mounting selections to save space and ease installation.
Features:
- Meeting EN837-1 and ASME B40.100 specifications allows for international use
- R110 and NGV 3.1 approvals
- Designed to meet MSL Helium leak test of 1 x 10-6 scc/s
- All-stainless steel movement
- Socket welded to case
- FlutterGuard™ standard on dry gauges
- Cost effective
Applications:
- Oil and Gas
- Natural Gas Transmission and LNG
- Machine Automation
- Irrigation equipment
- Hydraulics and Pneumatics
- Hydrogen and Technical Gases
- Hydrogen Cell/Applications
- Pumps and Compressors
- HVAC-R
- Ammonia and Refrigeration Services
- Chemical and Petrochemical
- Energy
- Food and Beverage
Reference:
T5500E Process Pressure Gauge with output
Description:
The Ashcroft® T5500E process gauge with integrated pressure transmitter output combines a pressure gauge and pressure transmitter; reducing costs for multiple instruments. This model can be integrated into safety and data acquisition systems. An ideal product when pressure measurement needs to be monitored or controlled.
Features:
- All-stainless steel movement
- Easily adjustable micrometer pointer
- Socket welded to case
- PLUS!™ Performance (optional)
- Integral transmitter with 4-20 mA output
Application:
- Hydrogen and Technical Gases
- Pharmaceuticals
- Pumps and Compressors
- Pulp and Paper
- Energy
- Machine Automation
Reference:
VD Series Pneumatic Differential Pressure Switch
Description:
The Ashcroft® VD pneumatic differential pressure switch is designed for use on tough applications where no electric power is available and uncompromising protection is required. The features of this switch along with its proven technology provide a stable, long-lasting product. Ideal for pressure control, safety shutdown or alarm operations.
Features:
- Selection of wetted materials
- Adjustable setpoints from 15% … 100% of range
- Precise repeatability of setpoint
- Wide variety of pressure connection thread options
Application:
- Water and Wastewater
- Chemical and Petrochemical
Reference:
A Series Explosion Proof Pressure Switch
Description:
The Ashcroft® APA and APS explosion proof miniature pressure switches are designed for pressure control for applications in harsh or hazardous locations. The explosion-proof construction provides superior protection, while its compact design allows for easy integration into custom equipment or systems. Ideal for pressure alarm, shutdown or process control within hazardous areas when limited size and compatibility are required.
Features:
- Expanded selection of pressure and electrical connections.
- SIL 3 Capable
- Wide operating temperature -40° to 89°C
- Explosion-proof housing provides uncompromising protection
- Compact, 316L stainless steel housing and wetted materials
- FM, UL, CSA, ATEX and IECEx hazardous approvals
- CE, CRN and 3A approved
Application:
- Oil and Gas
- Machine Automation
- Hydrogen and Technical Gases
- Pulp and Paper
- Pharmaceuticals
- Pumps and Compressors
- HVAC-R
- Chemical and Petrochemical
- Energy
- Food and Beverage
Reference:
ZX12 Pressure Transmitter
Description:
The Ashcroft® ZX12 high purity transmitter is ATEX and IECEx approved for use in hazardous locations. The compact design allows for high density installations, while the 316L electropolished stainless steel construction is ideal for use with many compatible gases and provides excellent resistance to hydrogen embrittlement.
Features:
- Ultra-stable CVD sensing technology
- Low internal volume (0.9cm³)
- ATEX and IECEx Type Ex ec (increased safety) approval
- Class 100 / ISO Class 5 cleanroom packed and double bagged
- High EMI/RFI immunity rating
Applications:
- Machine Automation
- High-Purity Gas Delivery Systems
- Gas Sticks
- Process gas analyzers
- Exhaust gas for CVD and etching equipment
Reference:
DP55 Process Pressure Transmitters
Description:
The ASHCROFT® DP55 Platinum Series Differential Process Pressure Transmitters are used worldwide for supreme accuracy continuous data Acquisition in the oil & gas, chemical, power, water and waste water industries, optional in hazardous applications.
Features:
- Strong dual diaphragm
- Active temperature compensation
- Flow measurement with SQRT function
- Simple Push-button menu navigation
- HART® DTM available for Microsoft Windows® OS
- ATEX and IEC Ex approval for hazardous area (optional)
- Rugged stainless steel construction
Application:
- Water and Wastewater
- Chemical and Petrochemical
- Energy
- Oil and Gas
- Level and Flow Measurement
Reference:
GC35 Pressure Transducer with Switch Option
Description:
The Ashcroft® GC35 is a compact rangable indicating pressure transducer with analog scaling, switch outputs and digital display. This device can be used as an indicating transducer or as an electronic level switch. Incorporating field-proven thin film sensor, this highly reliable transducer is an ideal choice for optimizing instrument costs in both pressure indicating and switch applications.
Features:
- Easy local adjustments using 3 pushbuttons
- GloBand™ display provides 360-degree visibility
- Compact, rugged construction
- Simple Push-button menu navigation
- All-stainless steel sensor element
- Min. / Max. function records low and high pressure events
- 3-in-1 capability: digital pressure gauge, switch and transducer
- Programmable switch setting and analog scaling
Application:
- HVAC-R – Ammonia and Refrigeration Services
- Machine Automation – Hydraulics and Pneumatics
